Switch gear. Rotary operation L/H integral clutch lever Start or Horn Lights High Low beam Turn

Switch gear. Rotary operation L/H integral clutch lever Start or Horn Lights High Low beam Turn
  • Click to enlarge

£10.79 £8.99 ExVAT

Product Code: 1622

Switch gear. Rotary operation L/H integral clutch lever Start or Horn Lights High Low beam Turn

Cast alloy body

M8 R/H mirror thread

Short lever 140mm from pivot to end with Micro switch

Latch in type cable

Light switch rotary action High Low beam

Turn L & R Off

Horn or start Momentary push

Wire colours function

Black = Neg or Pos feed for horn

Pink = Low beam +

Blue = High beam +

White = Feed in +

Grey = Flasher feed In+

Purple = Left turn +

Blue = Right turn +

Orange = Horn neg or poss feed



Clutch switch Yellow & Black make ad break

2 x 2 Pin Female plugs

1 x 6 Pin Female male pins

Product Code 1622
Condition New
Weight 0.3Kg
