220cc & 270cc. Engine 6.5BHP Ideal go kart engine or drift trike

NOW ALSO IN BLACK

Red Engine 270cc 9.8BHP  20mm shaft

Black Engine 220cc 8.5 19mm shaft

Great priced little engine smooth running

Crank rotation anti clock as you look at the drive side, Clock wise as you look at the pull start side.Crank rotation anti clock as you look at the drive side, Clock wise as you look at the pull start sid

5mm key way

Thread in end of crank is 5/16 UNF

We have heavy duty centrifugal clutches that bolt on the shaft with 420 sprocket 10T see drop down option 19mm for black engine only, we don't stock one for the 270cc engine.

Single 4 stroke OHV

Bore and stroke 68mm x 54mm

196cc

Compression ratio 8.5 to 1

6.5 BHP 4.8KW

Torque 13.2NM

TCI ignition

Engine oil 0.6L 10/40 semi "NO OIL IN ENGINE WHEN SHIPPED"

Petrol tank capacity 3.6L

Dimensions 370mm x 300mm x 370mm

Net/dry weight 15Kg

Bolt on base hole centres 160mm x 75mm

Governor controlled revs, if you wish to run on non governed carb you are a risk of exploding the flywheel.

Engine must be mounted so the base of engine is horizontal or it will suffer with oil starvation as its only splash feed. Also can cause it top pick up oil hand hydraulic bending the crank, conrod, or snapping pull starts.

Also work out how much power you need to drive your machine as over loading will cause engine damage.

Slights dents on fuel tanks..
