Inlet manifold, 20mm bore straight back, overall height 99mm XS-59-1

Inlet manifold, 20mm bore straight back, overall height 99mm XS-59-1
  • Click to enlarge

£9.98 £8.32 ExVAT

Product Code: 6644

Inlet manifold, 20mm bore straight back, overall height 99mm XS-59-1

Tips forwards 10 degrees if held on the flat, most engines tip up 5 degrees

Manifold to head flange bolt centres 45mm M6 hole

Manifold to carburettor flange 48mm bolt centres M6 holes, Holes sit above centre line “Honda style”

Supplied with heat spacer and gaskets to suit, please note spacer and gasket sizes don’t always match 100% to manifold bore size.

Cast alloy

Product Code 6644
Condition New
Weight 0.2Kg
