Inlet manifold, 28mm bore Multi hole off set or straight back, overall height 81mm ZL-106

Inlet manifold, 28mm bore Multi hole off set or straight back, overall height 81mm ZL-106
  • Click to enlarge

£9.98 £8.32 ExVAT


Product Code: 6646

Inlet manifold, 28mm bore Multi hole off set or straight back, overall height 81mm ZL-106

Tips forwards 5 degrees if held on the flat, most engines tip up 5 degrees

Manifold to head flange bolt centres 45mm M6 hole

Manifold to carburettor flange 48mm bolt centres M6 holes, Holes sit above centre line “Honda style”

Supplied with heat spacer and gaskets to suit, please note spacer and gasket sizes don’t always match 100% to manifold bore size.

Cast alloy

Product Code 6646
Condition New
Weight 0.2Kg
